YIH KUAN ENT CO., LTD.
Product Description :
The Plano Milling Head (Gantry Milling Head) are commonly used milling machine heads such as gantry milling machines, boring milling machines, and double-head milling machines. Uses include rough milling, finishing milling, boring holes... and other processing requirements.
The left and right vertical milling heads offer excellent flexibility and adaptability. Their adjustable angles and swivel capabilities enable operators to perform angular milling, drilling, and other complex operations with ease. They are compatible with different milling machines, providing a seamless integration into existing setups or as a valuable addition to new milling machine installations.
1. IK milling heads can upgrade or replacement your existing machine body, milling machine or special machine and also it can bring more stable and high-quality machining benefits for work piece cutting.
2. It is used for mold manufacturing or precision processing.
3. The machine processing for travel is 320 mm. We also provide “No slide” format.
4. This product is used in Gantry (Plano) Milling Machine (vertical / horizontal), suitable for heavy metal cutting.
5. Plano milling head series offer accessory head for you to optional.
It will apply for multi-angle machining to upgrade efficiency and longer machining range.
6. This product of standard motor is 10HP. We also offer 12.5HP for you to optional.
7. Offer pneumatic blade locking device, bearing guide screw, pneumatic leveler for you to optional.
8. There are 10 models in IK Plano Milling Machine Head Series.
GPM CO.,LTD.
Product Description :
Product features :
■ High speed and long time operation & Reducing thermal deformation
● Tool drive speed <6000rpm; continuously operation allowed
● Tool drive speed at 8000rpm; continuous operation for 30mins, thermal displacement of tool disc <10µm, temperature <65°C
■ High pressure coolant : 70~150bar
■ PT-100 high precision temperature sensor
HC FENG CO., LTD.
Product Description :
FOODIE (Chip/Sludge Removal Machine) works for :
Filtration/Removal of excess components
Chip/Sludge Removal
Fine Chip Removal
No downtime
No consumables
Backwater automatically & simultaneously
Air pressure drive w/o a plug
Vertically fast filter drying up to 90% efficiency
Precision filters effective up 20% for super filtration micro-fines
Easy to move
Filter accuracy can be adjusted
Extend cutting fluid life
FACTORY AUTOMATION TECHNOLOGY CO. ,LTD
Product Description :
CNC Vertical Lathe VL-25M
Description
✔Unique RAM Exchange Interface Design
The RAM has three special features. First, the unique interface design enables automatic tools exchange.
Second, the built-in power tools provide milling function.
Third, the precision indexed positioning facilitates wide milling and turning applications. Such characteristics can keep free of cutting force applying on bearing, thus prolonging the bearing lifespan.
✔Worktable with high loading capacity
The maximum allowable load of the worktable is 20 tons with a diameter of 2,700mm and it utilizes high-rigidity, high-precision crossed roller bearing with proper preload that is capable of resisting cutting load from all directions.
Specification
VL-25M
➣Capacity Other Item
Max turning diameter Ø3000 mm
Max turning height 1800 mm
Max torque 32200 N-m
➣Table
Size mm Ø 2700
Table load 20000 kg
Table rotation 1.6~160 rpm
Motor α40, 6000i
Motor(continuous/30 mins) 37/45 kW
➣Stork and Rapid
X axis stroke(Horizontal)(RAM) 2100 mm
Z axis stroke(Vertical)(RAM) 1200 mm
X axis feed rate(RAM) 0-8000 mm/min
Z axis feed rate(RAM) 0-20000 mm/min
Z axis stroke(Vertical)(Cross rail) 1500 mm
Rapid of cross rail 400 mm/min
➣Automatic Tool(Changer)
Tool number 1cover+5turning+6milling, ISO50
Shank size □32, Ø32/Ø40/Ø50 mm
➣Servo Motor
Table AC 37/45 kW
Cross rail AC 5.5 kW
Hydraulic power AC 3.7 kW
Table lubricating AC 0.37 kW
Slide lubricating AC 0.025 (2 set) kW
X axis α30i kW
Z axis α40iB kW
Power spindle 15/18.5 kW
➣Dimension
Floor space(WxDxH) 6250x4696x6410 mm
Machine weight 30000 kg
TAIWAN MORE-CASH VILLAGE CORP.
Product Description :
For 2mm-13mm Twist Drill Re-sharpening , Angle 90°-140°
For 3mm-12mm End Mill Re-sharpening
Twist Drill:
1. Precise Grinding Results , Precision Assurance within 0.02mm
2. Easy to Operate , grinding a drill within 10 seconds.
End Mill
1. Adjustable Cutting Face Angle and Width
2. Easy to Operate , grinding a End Mill within 60 seconds.
Special Design High Accuracy Alloy Steel Collets
Accurate Grinding consumption 0.2mm
High Efficiency DC motor
Stable Quality Diamond Dust Grinding Wheel
Considerable Design, Invisible Tool Box, Delicate & Friendly Use
Portable Design with only weight 14.2 kgs.
CHING HSYANG MACHINERY INDUSTRY CO., LTD
Product Description :
1. Vertical slideway provides up and down too feed and withdrawal,
ensuring tool operating life and high sawing accuracy.
2. In European design, this model is driven by multi-set gears, suitable for
heavy-duty cutting, featuring stable accuracy.
3. Elaborately designed feeding system is patented for its floating type.
Feeding has high precision.
4. Unique clamp design provides powerful and tight clamping.
5. Automatic slideway oil lubricating assuress long machine operating life.
6. Using PLC, this unit has no connection points, no defects, and is easy to
maintain.
7. Automatic cooling fluid circulation assures that cut faces are smooth.
8. Control buttons are located together, allowing for simple and
convenient operation.
9. Equipped with electronic type saw blade protection device.
10.Equipped with electronic type sawing amount setting and counting
device.
11. Automatic non-material machine stopping device.
12. Saw dust is treated together, convenient and clean.
13. Equipped with digital display for easy length adjustment, quick and
accurate.
14. Chuck pressure is adjustable, ensuring that the tubes will not deform.
15. Gears gap offset.
16. Can make sequential setup for sizes, positions, quantities of the disc
sawing machine is advance on time.
17. NC control angle, freedom to set up, cutting angle agreement, accurate
and quick.
18. Human machine interface machine. Easy to operate and available for
various cutting works.
19. The linear rail with a servo motor and a ball screw is employed so as to
ensure feeding fast and accuracy. The tolerance is +/-0.01mm.
GP MACHINERY CO., LTD.
Product Description :
Features:
The RGB system (Ram Gear Box) is the most complete solution within this family, with important technological contents, that combines high torque performance in small dimensions particularly appreciated for vertical (gantry or double column) and horizontal axis machine tools. The general characteristics are similar to the RTS
Products:
．Automatic attachment system for the accessories (like heads or extensions)
．Multitasking machining operations.
．Easiness of assembly and maintenance on the machine with:
．Quick connections and couplings positioned at the top of the RAM
．Possibility of easy and quick extracion of the spindle from the front of the RAM.
ACCUTEX TECHNOLOGIES CO., LTD.
Product Description :
AP series casting has compound table design by Y axis column moving. The center of gravity is always located between 2 linear guideways of X axis table. X and Y axes are independent without accumulation error for less deformation by FEA (Finite Element Analysis). Improved maximum loading weight is up to 1000kgs. The Bi-repeatability is less than 2.5μm after 5 times
laser calibration.
SHARPMAX TOOL INC.
Product Description :
● Periodic cutting stree is effectively suppressed by
continuously changing outer teeth spacing,allowing
for chattering control.
● Excellent anti-vibration performance compatible in a
wide variety of milling for exotic alloys including
SUS,inconel,and Titanium.
● Reduces chattering for high-speed and high-feed
cutting.
● Ultra-smooth coating with significantly
improvedcoating hardness and heat resistance
improves tool live in heat resisitive ally maching.
