LNS TAIWAN CO., LTD.
Product Description :
The SL65 S is an entry-level alternative for spindle length bar stock feeding. The SL65 S is designed for simple applications, especially for standard production parts, and for medium and large production runs.
●The SL65 S permits easy adjustment of the diameter.
●The operator-friendly remote control ensures the interaction between the bar feeder and the lathe.
●The SL65 S retraction system facilitates access to the lathe without compromising the precision of the alignment.
Fulson Industrial Co., Ltd
Product Description :
This machine is the crystallization of the technology that Fushun has carefully researched for many years. It has a stable appearance and a strong structure. Various operating handles and movable operating panels are within the operator's best line of sight and the most comfortable operating position. This is in line with the ergonomic design. Excellent models, providing you with higher work efficiency.
Spindle mechanism: The spindle is supported by five ultra-precision beveled ball bearings. Stable and strong main shaft structure, can withstand heavy load grinding.
AC servo motor lift drive: C3-level drive screw, driven by AC servo motor, with large torque, fast speed, and high positioning accuracy. With the full CNC system, the feed accuracy can reach 0.0001mm or 0.001mm.
Two lines and one hard track: Z-axis and Y-axis purchase high-precision line rails, and cooperate with high-precision ball screws, which can make the action smooth without lag; , maintaining accuracy without distortion.
Front and rear transmission speed control: The continuous movement speed of the saddle is driven by AC servo motor to obtain good surface grinding accuracy.
TAIWAN MORE-CASH VILLAGE CORP.
Product Description :
For 2mm-13mm Twist Drill Re-sharpening , Angle 90°-140°
For 3mm-12mm End Mill Re-sharpening
Twist Drill:
1. Precise Grinding Results , Precision Assurance within 0.02mm
2. Easy to Operate , grinding a drill within 10 seconds.
End Mill
1. Adjustable Cutting Face Angle and Width
2. Easy to Operate , grinding a End Mill within 60 seconds.
Special Design High Accuracy Alloy Steel Collets
Accurate Grinding consumption 0.2mm
High Efficiency DC motor
Stable Quality Diamond Dust Grinding Wheel
Considerable Design, Invisible Tool Box, Delicate & Friendly Use
Portable Design with only weight 14.2 kgs.
WELE MECHATRONIC CO., LTD.
Product Description :
1.立車主軸轉盤以進口交叉滾子軸承設計，確保重負荷的能力及長期的精度壽命。
2. Z軸226 mm方型滑枕搪孔軸採硬軌配Turcite B結構，VTC1612-CW標準行程900mm。
3.底座、立柱、橫樑、工作台等大型鑄件依製造需要，經由最新的3D設計，剛性最佳化，並以
多年經驗訂定有效的退火程序以消除殘餘應力，多年實際應用經驗，確實能達成有效的長期精
度保持性。
4.X、Z軸標準配備採用「雙編碼器」的「雙」半閉環回饋系統，經濟有效的提高各軸的定位精度。
(X、Z軸可選購德國Heidenhain或西班牙FAGOR光學尺)。
5.VTC-CW標準刀庫容量為16P(16儲位)，車刀型式及分配數目可依客戶要求處理。
6.主軸箱等關鍵零件係利用自有的「大型臥式鏜孔機」及「大型高精度三次元量測儀(三座標量床)」
確實達成應有的加工精度，確保優良的組裝基礎。
7.承襲歐美先進工具機廠的標準，以嚴格維護的「1.2米x1.2米」高精密度的方形標準平板做為精密
精度的基礎，對各項關鍵零件進行精密鏟花(刮研)，使機器的各處結合面和滑動面均能達到正確的
幾何精度，確保機器應有的精度和壽命。
8.搭配高規格的Fanuc數控系統，標準功能包含：15吋彩色液晶螢幕、Fanuc全鍵式操作面板、
2MB記憶容量、Ethernet網路接口、Flash記憶卡插口、剛性攻牙及各種特殊補間(插補)等多項
高規格功能，能經濟有效的滿足各種使用需求。
9.採用的各項配套零組件均經過長期使用驗證，可確保機器長期運行的可靠性。
10.完整的品檢測試流程，搭配先進的自動光學直準儀、雷射干涉儀、球桿檢測儀、線上動平衡儀等
精密檢測儀器，確保出廠的機器都能達到設計的性能和應有的功能。
11.經驗豐富的研發團隊，突破老舊的包袱，協助客戶達成各種特殊需求。
12.兼具經驗和熱誠的服務團隊和完整的服務體系，可以及時有效的讓用戶的機器長保最佳使用狀態。
LNS TAIWAN CO., LTD.
Product Description :
FEDEK FOX HM oil mist collectors provide the perfect solution for the collection of soluble coolant and oil mist. Specifically developed for the elimination of mist and wet machining operations.
LNS oil mist collectors will not only efficiently improve the working efficiency, optimize the productivity, but create a safety working environment for employees. Besides, bring the benefit of environment friendly.
●1st STAGE - PREFILTER: Made up by one or two cleanable metallic filters, this filter blocks bigger particles, and extend the filter lifetime. 2nd STAGE - CENTRIFUGAL FILTRATION: A special impeller ensures the centrifugal effect that enables the continuous evacuation of collected particles. 3rd STAGE - MAIN CARTRIDGE FILTER (with standard filter): Made up of different layers of media, the final stage provides an efficiency up to ISO ePM1 85% according to the ISO 16890 norm.
●The filtration efficiency of the OIL MIST COLLECTOR determines how clean the air is inside the workshop and how healthy is the environment for the operator. In addition, trained LNS technicians can provide onsite measurement of air quality to measure with high accuracy how clean the air is. The analysis is conducted using a sophisticated dedicated instrument.
●Best in efficiency - air flow regulating valve allow optimal filter lifetime. HM series are all equipped with air flow regulating valve which meets your requirements without install external ones.
KTR TAIWAN LTD.
Product Description :
ROTEX® GS is a three-part coupling, backlash-free under pre-stress. The different hub designs and the different Shore hardnesses offer the optimal coupling for each application in automation engineering. In spite of its vibration-damping characteristics it is torsionally stiff so that it is not necessary to make any concessions to accuracy even with highly dynamic servo drives. The ROTEX GS works with the modular system; a high variety of different hub designs is available which can be combined within one coupling size.
SHARPMAX TOOL INC.
Product Description :
● Designed for high performance rough machining of
Titanium and other exotic materials.
● Optimum performance with maximum chip load per
tooth and efficient chip formation with higher
volume of metal removal.
● Exclusive PVD coating for long life.
● Vibration Free.
JAINNHER MACHINE CO., LTD.
Product Description :
The precision hydrostatic spindle ensuring long-term stable operation, improved machining accuracy and extended grinding wheel life. The grinding wheel spindle speed can reach up to 2900 RPM, with a peripheral speed of up to 60 m/sec, making it ideal for ultra-precision grinding.
Through auxiliary functions such as automatic grinding wheel balancing system, touch probe gauge, auto in-process gauging, and wheel crash control device, the machine ensures long-term stable operation, achieving high-precision, high-efficiency grinding while ensuring equipment safety.
Equipped with a self-developed "SMART HMI", offering intuitive operation, reducing setup time and improving user convenience.
