HO CHEN MACHINERY & ELECTRIC IND. CO., LTD.
Product Description :
X axis travel:
Single movement: 2550 mm (100") inch
Dual movement: 1275 mm (50") inch
YZ axes travel: 850x600 mm (33"x24") inch
※Y axis can be increased to 1300 mm(51") (Option)
※Z axis can be increased to 1000 mm(39") (Option)
Work table: 3100x1600 mm (122"x63") inch
Max. Workpiece: 4100x2050x1250 mm (161"x81"x49") inch
Max. Workpiece weight: 22000 kg
Max. electrode weight: 500 kg
Machine net weight: 29410 kg
Oil level: 110-1000mm (4"-39") inch
Occupy size(LxWxH): 6480x6600x4600 mm (255"x260"x181") inch
Work Table to platen:
600mm Z travel machine: 1138-1738mm (45"-68")
1000mm Z travel machine: 740-1740mm (29"-69")
Filter： 4
Paper filter：8
Capacity：11300 Liters
Machine Features
> Windows CE controller
> A dialog window with picture description.
> Special repaired frames to quicken the maintenance speed.
> Close-loop design of digital feedback on three axes of the machine significantly increases positioning precision and ORBIT-CUT machining accuracy and efficiency.
> Simple operation interface.
> Common function keys are located on the operational panel for direct use.
> Hot key setting.
> ATC (automatic tool change) and C-axis 360° index can be installed; the process of coarse machining to ultra-fine machining can be completed at one time.
> Dialogue diagram provides various hole-expanding modes such as quick search of edge, centers and datum marks.
> Rich color graphic (the same resolution as a PC screen).
> Automatic multi-step machining (coarse, medium coarse, medium fine, fine, superfine)—up to 10 steps.
> Unlimited number of machining conditions can be saved as machining archives. Each set of machining conditions can be edited, modified or stored. They are easy to edit and easy to find.
> Automatic origin search and multi-point coordinate memory capability.
> 1/2 design capability, ARC automatic discharge waveform detection and automatic adjustment.
> Automatic center position detection, automatic compensation, search of hole center and deepest point; fixed hole machining (cyclic mode, independent mode), which is suitable for different machining conditions; Radial, circular, square, linear (vector), coning, 45° hole-expanding machining.
> Three-axis beeline, two-axis arc, three-axis helix.
> Chinese/English versions interface, metric/British system switch and Z-axis quick up, quick down, slow up and slow down capability.
> Lateral machining, three axes, six directions (plane rotation).
> All alarms describe the source, date and exact time of problem occurrence.
> Optical scale is applied for close-loop position control, enabling extreme position for machining.
> Automatic editing—settings can be done according to type of material, work piece size, machining depth, one side die clearance, final current and rate of electrode wear.
> CNC models possess conventional capability of consistent level of energy discharge, achieving stable and rapid machining and smooth high quality on machining surface while the rate of electrode wear is still low.
> Monitor page indicates machining path and orbital pattern in use.
PEIPING PRECISION ENTERPRISE CO., LTD.
Product Description :
*Automatic spindle polishing control.
*Keep the precision of spindle and no damage to spindle body.
*One setting for the maximum convenience of operation.
[After Use]
*Extend the life of cutting tools.
*Increase workpiece accuracy.
*Reduce the spindle vibration and extend the life of spindle.
YOKE INDUSTRIAL CORP
Product Description :
1. 360° rotation and 230°pivot
2.Rotatable under load due to its unique ball bearing design.
3.Manufactured in accordance with EN1677‐1 and the requirements of ASME B30.26
4.Certified by DGUV GS‐OA‐15‐04
5. Forged alloy steel, quenched and tempered
6.With the Grade 100 High‐strength alloy steel, WLL is increased without increasing swivel size compared to other Yellow Point models.
7.4:1 Design factor
8.100% Magnaflux crack detected
9.Proof load at 2.5 times the WLL
10.Fatigue rated for 20,000 cycles at 1.5 times the WLL
CHANDOX PRECISION INDUSTRIAL CO., LTD.
Product Description :
大尺寸中實夾頭，適合立式車床加工使用。
1.鋼製外殼具備穩定的機械性質以及高轉速，提昇加工穩定度與彈性。
2.特製黃銅防塵密封條，減少進入夾爪內部的切屑或雜質，降低故障機率。
3.提供多種鼻端規格的連接板方便安裝與更換。
1. Steel Chuck body have stable Mechanical Behavior and high rotating speed, it could raise your working stability and flexible machining applications.
2. Brass dust sealing which installed on the both side of slideway, can prevent the scraps into the chuck when machining, and keep the working stability.
3. We provide different flange plate for adapt with different A2 Spindle Nose size, it’s easier and more convenient for installing and changing the chuck.
FONGEI INDUSTRY CO., LTD.
Product Description :
-It can process various chips created by complex machining.
-Equipped with a filter system for processing cutting fluid with 0.5mm filtrating accuracy.The roller filter screen features a self-cleaning function to ensure the dependability of filtration.
-Equipped with an industry-leading overload protection device the extends the parts service life of the chip conveyor.
ADLEE POWERTRONIC CO., LTD.
Product Description :
Product applications:
Internal & External grinder 、Conveying equipment、Coffee roasting equipment、Centrifugal equipment、Polishing equipment、Emulsifying machine、Glass edge grinder、Auto polisher grinder, etc.
Brushless DC Motor
1. Minimize EMI and maintenance free. Low noise.
2. Specialized design to have smooth shaft rotation and improved reliability.
3. Brushless DC motor is light weight and compact size, higher power density, higher torque density and higher efficiency than conventional motors.
4. The structure has an excellent behavior in energy saving during heavy load operation. The high efficiency range is much wider than other motors too.
5. Built-in NTC thermal resistor to prevent over heat problem.
AC Driver
1. Available for all control interfaces, ex. RS 485, direct signal, PLC, HMI.
2. Convenient 220VAC driver power input from 60W. No more 24VDC power supply.
3. Built-in 24VDC mechanical brake control power.
4. Real motor speed display and signal output.
5. Panel control is always enabled with removed control or terminal control or RS485 control. Convenient for system set up or maintenance.
6. Excellent speed stability. Open loop and close loop speed control for selection.
7. With 0~5VDC, 0~10VDC and 4~20mA speed analog input.
8. Over current / heat / voltage, electric motor lock protection.
LNS TAIWAN CO., LTD.
Product Description :
The GT342 has been designed for maximum productivity and return over investment in the sliding headstock range, for long bars from 3 to 42 mm.
●OPTIMUM GUIDING - Polyurethane guiding elements dampen vibrations to ensure optimum performance.
●DIAMETER CHANGEOVER - A changeover within the same guiding elements takes less than a minute. Their symmetrical shape and tool-free positioning prevent any mistakes, bringing the barfeed into production safely and quickly.
●UPGRADED FRONT REST - V-shaped guiding elements adapts to any round bar diameter, dampening any residual vibration and noise within the whole diameter range.
HAWE Hydraulik Singapore Pte. Ltd. Taiwan Branch
Product Description :
Directional seated valves are a type of directional valve. As cone valves they are tightly sealed, with zero leakage in the closed state.
The directional seated valve type ROLV is available as a 3/2, 4/2 or 4/3-way directional seated valve with different plug types. The patented assembly consists of two parts: a round basic valve with the valve inserts, and an adapter plate which can be designed for manifold mounting with nominal size NG 6 as the
standard connection pattern, or for direct pipe connection.
Additional elements such as a check valve, a restrictor (on the consumer side) and/ or restrictor check valves can be integrated, depending on the functional requirement and adapter plate. The type ROLV can be combined in the valve bank type BA with other types of valves.
Features and benefits
■ Dirt-resistant design with high switching reliability
■ Interchangeable solenoid for greater flexibility and easy servicing
Intended applications
■ Machine tools (cutting and non-cutting)
■ Clamping tools, punching tools, fixtures
■ Testing machinery
■ Wind turbines
