WELE MECHATRONIC CO., LTD.
Product Description :
1.高剛性高穩定性結構
A. 底座：機器底座採用整體式鑄件，有效確保機器剛性。Z底座採4線軌設計，全行程範圍內直接落地支持，有絕佳的剛性及穩定性，確保整體長期幾何精度。
B. 滑座：滑座採用整體式鑄件，支撐於Z底座上，4線軌設計增加滑座負載剛性。
C. 立柱：立柱採用整體式鑄件，有效確保機器剛性；且固定不移動，大大減少主軸移動行程中所帶來的幾何精度誤差影響。
2. XYZ三軸及W軸導軌均採用先進的超重負荷型「滾柱」線性導軌，大幅度提高導軌「剛性」和「重切削能力」，也繼續保有「低摩擦力、低磨耗、低遲滯現象、低失位量、高速度、高精度、高動態特性、高壽命、不需調整」等線性導軌的優良特性。
3.XYZW四軸的均有過負載保護，如因誤操作造成撞機，可有效降低對機器的損傷。
4.雙編碼器回饋裝置（配置於XYZ三個進給軸)，B軸採用(圓光栅-角度編碼器) 廠牌：發格Fagor。
5.主軸箱等關鍵零件係利用「大型臥式搪孔機」及「大型高精度三次元量測儀（三座標量床）」確實達成應有的加工精度，確保優良的組裝基礎。
6.鞍頭：110主軸系統配備搪孔軸直徑110mm，搪孔軸行程W=500mm、3500 rpm(兩檔齒輪箱)。搪孔軸為氮化處理高硬度合金鋼件，前段支持使用傳統的硬化襯套外，後段附加線性導軌的加強支持，借助滾動低磨耗的特性，增長搪孔軸的精度壽命。
7.主軸前軸承採用直徑150mm的高精度主軸軸承，加上改良設計的軸承配置及潤滑設計，有效的提高主軸剛性和壽命。
8.主軸鬆刀採浮動式抓鬆刀裝置，鬆刀時不會施力於主軸軸承上，可長保主軸最佳精度；另，新式鬆刀缸配置設計，可使主軸於任一行程(W軸)位置換刀。
9.特殊設計的自動潤滑系統；潤滑油與切削液分開， 單獨收集可確保切削液的穩定性及工作環境的清潔。
10.刀庫採立柱側背式設計；刀庫與立柱接合，不同於落地型式，立柱固定不移動，刀庫與鞍頭配置可達成左右平衡架構，提高W軸動態穩定特性。
11.承襲歐美先進工具機廠的標準，以嚴格維護的「1.2米x1.2米」高精密度的方形標準平板做為精密度的基礎，對各項關鍵零件進行精密鏟花（刮研），使機器的各處結合面和滑動面均能達到正確的幾何精度，確保機器應有的精度和壽命。
12.採用的各項配套零組件均經過長期使用驗證，可確保機器長期運行的可靠性。
13.電氣箱採全密閉式循環熱交換系統，內部配線均參考德國工業安全標準，電源部份與訊號線區隔，以增加機器使用上的安全。
14.搭配高規格的Fanuc 0i MF Plus數控系統，標準功能包含：15吋彩色液晶螢幕、Fanuc全鍵式操作面板、1280米記憶容量、Ethernet網路接口、Flash記憶卡插口、Manual Guide i圖形對話式編程、剛性攻牙、手動剛性攻牙、AI contour control II等多項高規格功能，能經濟有效的滿足各種使用需求。
15.完整的品檢測試流程，搭配先進的自動光學直準儀、雷射干涉儀、球桿檢測儀、線上動平衡儀等精密檢測儀器，確保出廠的機器都能達到設計的性能和應有的功能。
16.經驗豐富的研發團隊，突破老舊的包袱，協助客戶達成各種特殊需求。
17.兼具經驗和熱誠的服務團隊和完整的服務體系，可以及時有效的讓用戶的機器長保最佳使用狀態。
PROTH INDUSTRIAL CO., LTD.
Product Description :
1.10" touch panel.
2.The Y-axis(cross) and Z-axis(vertical) are driven by serve motor.
3.Use MPG in Y-axis and Z-axis.
4.Use PLC controller.
5.Flow control regulator is used in longitudinal way for using well.
6.Auto down feed system includes auto dresser and compensation.
7.Machinable content : surface, criss-cross, plunge, form pitch.
QUASER MACHINE TOOLS, INC.
Product Description :
The MV1 series machines have a legendary history of high quality and proven performance, the New MV184 series has an even greater degree of reliability and performance. The design concepts of the new MV184 series combine advanced technology, performance and value for various machining applications.
Quaser produces this machine layout with the state-of-the-art digital design. Taking into consideration easy repair to reduce downtime. The MV184 series is the choice to increase part production.
YEU-LIAN ELECTRONICS CO., LTD.
Product Description :
OEM/ODM circuit board combined adapter board, relay board, patch board and I/O board into one piece - all optimized to customers' needs. The PCB circuit board can customize various controllers such as FANUC, MITSUBISHI, SIEMENS, FAGOR, HEIDENHAIN and industrial types. Apply to CNC machines like lathes, milling machines, turning, multitasking machines, machine tools or industrial machinery.
TAIWAN MACHINE TOOL CO., LTD.
Product Description :
TMT TG series with meticulous design, is your best choice in precision finishing. Multi-performance, while satisfy different machining demand. Work table can be mounted with APC, 5 Axes or fix table.
-High cutting rigidity with ganty type structure design.
-Compact design less floor occupation.
-Without carring ATC system on moving parts to make it lighter, make sure cutting without vibration.
- Cutting area isolation to ensure the transmission system life longer and easier to install linear scale.
-High efficiency servo drive ATC system, C-C(T1-T2)only 4sec., with high stable performance.
-ATC install at the center of basement to reduce the width of machine to save the walking steps to loading and unloading workpiece.
HUI-JING ELECTRONIC CO., LTD.
Product Description :
Square Wave Type:
Product Features:
Output Mode: Line Drive
Signal Resolution Multiplier: 1, 4, 8, 32, 128~256
Output Pulse Count = Gear Teeth Count x Signal Resolution Multiplier
Voltage: 5V
Protection Level: IP68
Sine Wave Type:
Output Mode: Line Drive
Signal Resolution Multiplier: 1VPP (Sine Wave)
Voltage: 5V
Protection Level: IP68
進桜電機株式会社
Product Description :
We are a manufacturer of induction motors.
With advanced high-speed and high-precision design and manufacturing technologies, we provide integrated production services—from design to final manufacturing—tailored to customer requirements. Our products serve a wide range of applications, including specialized processing machinery, woodworking equipment, metal and resin processing machines, FPD (Flat Panel Display) equipment, as well as ultra-specialized motors for pharmaceutical, chemical, and aerospace industries.
Since we manufacture the stator coils—the core component of the motor—in-house, we are able to design and produce custom spindle motors according to each customer’s specific needs.
CAPTAIN SCIENCE CORPORATION
Product Description :
GENERAL DESCRIPTION RTB bearings (standabearings consist of a L-shaped inner ring - complet-ed with a washer -, an outer ring, two roller thrust bear-ings and a cylindrical roller bearing, full complement.Unitec has modified the inner design of RTB bearings and therefore load-carrying capacity and stiffness values may differ from the ones of past designs indicated on previous catalogues. The axial and radial load ratings have been calculated according to UNI ISO 76 and UNI ISO 281 standards.
