FAIR FRIEND ENTERPRISE CO., LTD.
Product Description :
★Gantry type structure
- Designed with a gantry type structure, the Feeler U800-5AX 5-axis machining center has the feature of spacious machining space, allowing large workpiece to be loaded and unloaded with ease. It is also convenient for operator to check the current machining condition at any time.
★U-shaped construction of base and column
-The advanced U-Shape structure significantly increases structural rigidity and machining accuracy.
-X.Y.Z axis rapid traverse rate reach 48m/min.
- Suitable for equipping with a large diameter of rotary table.
★Three axes overlap and separated from two rotary axes
- This design avoids a distance between the machining point and the intersection point of two rotating axes.
- Easy to compensate for the errors of radius on rotating axes and movement on three linear axes to ensure the machine's stability and accuracy.
★Separated design for three axes moving area and machining area
- This design feature not only makes chip removal more convenient, but also enables better chip-prevention capability of the machine.
- The rotaary shaft speed is increased by 800 rpm, which makes the turntable have a high-speed turning function.
YING HAN TECHNOLOGY CO., LTD.
Product Description :
■The specially designed software allows the operator to design the desired graphs on characters with ease, then machining can be conducted immediately.
■The automatic height adjustment function enables the focal length to be maintained at a constant status, thus ensuring the consistency of cutting quality.
■Small heating area on the workpiece eliminates workpiece deformation problems.
■This machine is equipped with a constant temperature water chiller, enabling the machine to withstand long time continuous running with stable performance.
■The enclosed splash guard can prevent damage to personnel due to the strong laser light.
■The shortest cutting tail is ≥0 mm.
HC FENG CO., LTD.
Product Description :
Replenishing Fluid automatically, accurate cutting fluid concentration. One equipment to multiple CNC machining centers. The supply line can be as long as 20 meters.
#Filtration by 3 filters #Sterilization by ozone # Oil-water mixer to precise mixing 0-10% cutting fluid #Stirring device avoid cutting fluid become stagnant water. #oil tank level meter for 50 gallon barrel low level detection.
ROLLCO TAIWAN CO., LTD.
Product Description :
Linear Unit QME is a complete and compact linear unit that consists of a linear table with linear ball bearings on hardened shafts and driven by ball- or lead-screw.
QME is available in the sizes 12, 20 and 30 mm. They are delivered ready for installation and thereby saves both design and assembly time. Selectable standard options are bellows, hand wheel, manual screw locking, mechanical position counter as well as double block units with left + right hand drive screws.
A wide variety of executions is available for quick delivery from our workshop.
HABOR PRECISION INC.
Product Description :
> Applications
Spindle, Linear Motor, Ball Screw, Grinding Liquid, CNC Cutting System, CNC Lathe, Other Machining Center
> Feature
Prevent deterioration of liquid.
Open coil type heat exchanger can prevent the obstruction problem of liquid circulating system.
Advance the speed of process.
Maintain the stability of dielectric fluid, advance the process quality.
Avoid fire risk cause by temperature rise and accumulating of dielectric fluid, advance the working safety.
Reduce the wastage of electrode.
Prevent the spreading of foul odor air, reduce the air pollution.
Easy operation and low noise.
Made of anticorrosive material.
MATECH INDUSTRIAL CO., LTD.
Product Description :
本數控橢圓車床係為解決汽油機與柴油機活塞的中凸變橢圓裙部之加工而設計的。
本機特性
*本數控橢圓車床採用線性伺服橢圓產生器，配合非接觸式0.0001mm超高解析度
回饋系統，具備高響應頻率、高精密度、高剛性等特點。
*由於此設備採用高效能控制核心及極短取樣時間的新一代控制器，可以獲得更快速
且精準的切銷路徑控制。
*本機部份採用全閉環式0.001mm光學尺回饋系統，近一部確保最家定位精度，並能
有效的消除熱干擾。
*新一代整合式橢圓控制器，由於不在需要資料傳輸，因此可以避免因為傳輸而導致的
雜訊干擾或資料遺失。
*編程軟體採用(看圖輸入法)編寫，操作者無須再耗費長時間學習，只要依照活塞圖面
標示的尺寸，輸入安加橢圓控制器即可，型線及相關橢圓路徑則全由控制器處理。
TAIWAN ASAHI DIAMOND INDUSTRIAL CO., LTD.
Product Description :
* Processing Method｜Grinding
* Applications｜Tungsten Carbide Blade Tool Processing
1. Excellent grinding ability, significantly reducing spindle load, save processing time and cost.
2. Tough texture and wear resistance characteristics to achieve the maintenance of tool dimensional accuracy.
* Processing Material | Tungsten Carbide
SAFEWAY MACHINERY INDUSTRY CORPORATION
Product Description :
Inserts / Jaw
Compatible with all safeway vises
Suitable for 3 types of material :
soft steel / hard steel / aluminium alloy
Each set includes 2 jaw plates
Gripper Set
Suitable for all safeway vises
One gripper contains :
holding teeth / dovetail / serration
MANFORD MACHINERY CO., LTD.
Product Description :
Turnkey solution of VU-620 product line enables Manford to process and optimize parts efficiently, enhance productivity and accuracy. VU-620 adopts low-pollution components and complies with eco-friendly regulations. Occupying compact floor dimensions is also one of the features of VU-620.
VU-620 offers high speed, high accuracy and more reliable quality. Twin doors design with wide open space is easy for loading workpiece. Movable column C-shape provides superior rigidity. Rotary table with one-piece iron casting provides excellent ductility and greater anti-vibration. Rotary table selection: standard worm gear, or double DD motor.
