HO CHEN MACHINERY & ELECTRIC IND. CO., LTD.
製品の説明 :
XYZ軸行程：1000x600x500 mm (39"x24"x20") inch
工作台：1250x750 mm (49"x29" )inch
最大工件：2000x1150x625 mm (79"x43"25") inch
最大工件重：4500 kg
最大電極重：350 kg
機器淨重：5700 kg
油位高度: 110-450 mm (4"-18" )inch
佔地面積尺寸(長x寬x高)：4010x4050x2880 (158"x159"x113") inch
電極板至工作台面距離：430-930 mm (17"-37")
過濾箱：2
過濾網：4
容量：1900公升
3D CNC WINDOWS CE 控制器特點：
> 本系統是採用Windows CE 控制器。
> 採以對話式視窗來呈現且搭配圖片描述功能。
> 具有專門維修畫面來加快維修速度。
> 本機三軸均採用數字尺回授之全閉環迴路設計，故能使定位精度及ORBIT-CUT加工精度及效率大幅提升。
> 具有良好且簡易的操作介面。
*常用的功能鍵都在操作面板上直接使用。
*具有快速按鍵功能。
> 可加裝ATC自動換刀及加裝C軸360度分度，可自動修飾從粗加工至超細加工一次完成。
> 對話式程式，提供各種擴孔模式(各種快速尋邊，尋中心、尋基準點功能)。
> 具有較高顏色的畫質（與PC相同高畫色）。
> 可做自動多段加工(粗→中粗→中細→細→極細)，最多可達10段。
> 加工條件採用加工檔案方式儲存，具有無限組加工條件，每組加工條件可直接編輯修改或儲存，編輯簡易查詢方便。
> 自動尋原點功能及多點座標記憶功能。
> 1/2設計功能及ARC自動放電波形偵測與自動調整。
> 自動中心測位自動補償，可尋孔中心尋孔最深點。定孔加工(循環式、獨立式)，適合不同加工情況。放射狀、圖形、方形、直線(向量式)、錐度、45°擴孔加工。
> 三軸直線、二軸圓弧、三軸螺旋。
> 中/英文版及公/英制切換和Z軸快上、快下及慢上、慢下功能。
> 單軸側放，三軸，六種方向(平面旋轉)。
> 所有警報都可詳細描述發生的問題點、紀錄時間、日期。
> 採光學尺Close-loop位置控制，精度高。
> 自動編輯。可依材質、面積、加工深度、單側間隙、最終電流、電極磨耗等設定。
> CNC機型同樣具有傳統式等能量釋放功能，加工穩定快速，電極消耗小，表面精度均勻。
> 監視畫面加工路徑顯示和圖形顯示功能。
KENTURN NANO. TEC. CO., LTD.
製品の説明 :
Our own manufacturing spindle can fulfill the coolant of axis also inhibit the heat and thermal deformation by using the Germany original OTT HSK-A63 drawbar system. Besides, the oil-air lubricating bearings can stand long-term cutting operation. The spindle, motor power is up to 25KW, speed 18000 RPM, using dualdrive chunk, can be used in vertical machining centers and medium gantry machine.
GP MACHINERY CO., LTD.
製品の説明 :
The Hiteco birotary heads series Tilt HX PLUS (90 °) are ideal for light alloys, composite materials and plastics working. Discover the liquid cooled electrospindles available with the various configurations.
Advantages:
1. Designed for machining composite materials, plastic and light alloys
2. Optimisation of the machining times thanks to the high positioning speeds
3. Excellent stiffness despite the light weight
CAPTAIN SCIENCE CORPORATION
製品の説明 :
Established in 1935 as a subsidiary of The Felters Company, originally working primarily in the shock/vibration field, UNISORB® has grown to be the leader in providing a full spectrum of advanced products and innovative engineering for the installation of a wide variety of capital equipment used in General Manufacturing, Metalworking, Testing and Verification, Printing, Power Generation, and a wide variety of other areas.
TAIWAN MORE-CASH VILLAGE CORP.
製品の説明 :
1.Convenient Design
X, Y axis workable professional structure enhanced high-
performance cutting accuracy.
2.Cutting Capacity
Cutting diameter: Ø3~16mm;
Cutting length of work-piece end: 15mmL/max;
3.Patented Radius cutting by Dual-motor driver
The hardened treatment steel is controlled well in virtue of
natural dissipation characteristic, cutting time is greatly
shortened as the work-piece is simultaneously rotated while
cutting.
4.Quick-Work-Changing System
The work-piece is quickly exchanged with prime quality 3-Jaw
chuck system.
5.Cooling System
Dry cooling is able to connect with various pressurized air and
vacuum cleaner achieved perfect cooling effect.
6.Cutting Disc
SD#100 for Carbide, CBN#100 for HSS
7.Optional Grinding Wheel For GS-13 GS-13
SD#100 thickness 5mm, 10mm for Carbide, CBN#100
thickness 5mm, 10mm for HSS
A.Carbide end mill cutting efficiency on GS-13
■ Ø 10mm 4 flute carbide end mill is cut by SD#100 cutting
disc takes 55 seconds.
■ Ø 16mm 4 flute carbide end mill is cut by SD#100 cutting
disc takes 100 seconds.
B.HSS end mill cutting efficiency on GS-13
■ Ø 10mm 4 flute HSS end mill is cut by E60WA cutting disc
takes 60 seconds.
■ Ø 16mm 4 flute HSS end mill is cut by E60WA cutting disc
takes 110 seconds.
QUASER MACHINE TOOLS, INC.
製品の説明 :
Flexible Manufacturing System provides a solution for
massive production or high mix low volume. Simple installation
design helps users to increase productivity in a short time.
The intelligent Automatic Pallet Change Cell has a compact
footprint design with, 6 or 8 pallet options. APC can be field
retrofitted even if the machine is settled months or years ago.
Robotic Tool Magazine Cell is a perfect match for lights out machining.
It also has a small footprint to maximize the user’s facility space.
6 manual loading pockets reduce tooling loading time efficiently.
RAISE PRECISION CO., LTD.
製品の説明 :
Our range of optical sensors comprises classic forked light barriers with red light or infrared technology. Still greater accuracy is offered by our laser light barriers, which even respond to tiny objects.
The special design with integrated air system is an optimal solution when it comes to contamination, as the air system prevents dust and dirt from collecting on the transmitter and receiver.
A further CAPTRON innovation is the product series of TCP measurement units with laser. TCP measurement units ensure a highly precise tool calibration and precise XYZ measurement in industrial robots. TCP measurement units are commonly used in robot-based automation processes in the metering and bonding technology, welding, soldering and in the food industry.
