ASMITH MANUFACTURING COMPANY
製品の説明 :
Dust-resistant, waterproof (IP66), resistance to heat and corrosion.
Patent: Pawl is fixed by 4 positioning points and the grooved shaft-bolt, easy for assembly and adjustment. Need only to slide the pawl through the shaft-groove to the correct position, more stable and accurate.
Left, right and top opening. The pawl moved forward and reversed vertically 3mm while the compression latch is opened and closed.
Used widely for door panel of general cabinet boxes.
Pawl can be easily positioned to accommodate the suitable compression.
In accordance with RoHS.
➤Material-body and lever: SUS304(stainless steel)-vibration ground and brushed finish in front.
➤Material-shaft, pawl and mounting bracket: SUS304(stainless steel).
FACTORY AUTOMATION TECHNOLOGY CO. ,LTD
製品の説明 :
CNC Horizontal Boring & Milling Machine
BMC-135TN Features
135 mm Spindle Diameter
Moving column construction
T Type Construction Base
➣Optional X/Y/Z axis travel, flexible for various machining requirements.
➣BMC-135TN can perform extreme precision machining, powerful milling and drilling processes among similar machines in the market.
This machines can be individually tailored to meet the costumer's requirements by choosing from comprehensive options and equipment.
➣Travel
Table cross travel (X): 3000/4000(option) mm
Head stock travel (Y): 2500/3000(option) mm
Table longitudinal travel (Z) : 1500/2000(option) mm
➣Table
Table size: 2200 x 2200 ｍｍ
Table load: 15000 kg
➣Spindle
Spindle Stroke (W): 800mm
Spindle Diameter: 135mm
Spindle Motor(continuous/30 mins) :30 / 37 kW
Spindle Speed range low : 30 / 37 kW
Spindle Speed range high : 579- 3000rpm
➣Machine dimension
Height: 5080/5525 mm
Floor space(W×Ｌ×Ｈ)：7200 x 7500 / 8200 x 8000 mm
Machine Weight: 33000/34000 kg
FACTORY AUTOMATION TECHNOLOGY CO. ,LTD
製品の説明 :
CNC Vertical Lathe VL-25M
Description
✔Unique RAM Exchange Interface Design
The RAM has three special features. First, the unique interface design enables automatic tools exchange.
Second, the built-in power tools provide milling function.
Third, the precision indexed positioning facilitates wide milling and turning applications. Such characteristics can keep free of cutting force applying on bearing, thus prolonging the bearing lifespan.
✔Worktable with high loading capacity
The maximum allowable load of the worktable is 20 tons with a diameter of 2,700mm and it utilizes high-rigidity, high-precision crossed roller bearing with proper preload that is capable of resisting cutting load from all directions.
Specification
VL-25M
➣Capacity Other Item
Max turning diameter Ø3000 mm
Max turning height 1800 mm
Max torque 32200 N-m
➣Table
Size mm Ø 2700
Table load 20000 kg
Table rotation 1.6~160 rpm
Motor α40, 6000i
Motor(continuous/30 mins) 37/45 kW
➣Stork and Rapid
X axis stroke(Horizontal)(RAM) 2100 mm
Z axis stroke(Vertical)(RAM) 1200 mm
X axis feed rate(RAM) 0-8000 mm/min
Z axis feed rate(RAM) 0-20000 mm/min
Z axis stroke(Vertical)(Cross rail) 1500 mm
Rapid of cross rail 400 mm/min
➣Automatic Tool(Changer)
Tool number 1cover+5turning+6milling, ISO50
Shank size □32, Ø32/Ø40/Ø50 mm
➣Servo Motor
Table AC 37/45 kW
Cross rail AC 5.5 kW
Hydraulic power AC 3.7 kW
Table lubricating AC 0.37 kW
Slide lubricating AC 0.025 (2 set) kW
X axis α30i kW
Z axis α40iB kW
Power spindle 15/18.5 kW
➣Dimension
Floor space(WxDxH) 6250x4696x6410 mm
Machine weight 30000 kg
TOP POWER MACHINERY ENTERPRISE CO.
製品の説明 :
The latest crumb collection and +1um precision filtration machine. This bottom debris recovery filter is equipped with a 1.5-inch large suction pump, which can quickly collect and dry the bottom debris and sediment in the water tank, allowing customers to clean it conveniently. This machine is equipped with a multi-functional stainless steel filter barrel that can collect coarse bottom debris. At the same time, using our patented technology, there is no need to replace the filter barrel, and it can continuously perform precision filtration up to 1um, thereby intercepting and filtering impurities and suspended particles in the water.
JIN LI CHENG CUTTING TOOL CO., LTD.
製品の説明 :
※Special chip out and geometric flute design. Excellent chip out perfomance without burrs. For various materials including the ductile stainless steel.
※Multinational patented drill point angle and double ute design. Great wear out resistance Keep long time precise drilling.
※With both function of Drill and Reamer design and its accuracy tolerance is within 0.01mm. It also can save tool change time while processing.
※With European carbide round bar and exclusive cutting angle design, We run the polish process on all the end mills, and it leads the tools easy to remove chips and keep the double life time than other competitors.
※Based on Europe composite coating with internal coolant holes, it leads the JLC at drill much longer life time and reduce customer lots of processing cost.
