HO CHEN MACHINERY & ELECTRIC IND. CO., LTD.
製品の説明 :
XYZ axes travel: 600x400x400mm (23.62"x15.74"x15.74")
W axis travel: 450mm (17.71")
Work table: 650x450mm(25.59"x17.71")
Max. Workpiece: 900x500x300mm(35.43"x19.68"x11.81")
Max. Workpiece weight: 700kg
Distance from table to guide plate:25~425mm(0.98"x16.73")
Machine dimensions: 1580x1250x2740(62.2"x49.21"x107.87")
Machine net weight: 1200kg
Electrode diameter: 0.2~3.0mm
Dielectric fluid: pure water ( dielectric oil for 0.2mm or below)
Filtration: Paper filter
Controlling axes XYZW
Monitor: 15” LCD screen
Input/output unit: LAN/USB
Min. Setting Unit: 0.001mm
Min. Moving Unit: 0.001mm
Graphical display: 2D
Machine Features
1. This system utilizes Windows CE controller.
2. Able to store data through USB and internet.
3. Dialogue window, along with picture description functions.
4. Touchscreen type interface.
5. Special repaired frames to quicken the maintenance speed.
6. Close-Loop design of digital feedback on three axis of the machine, significantly increases positioning accuracy.
7. Possessing good and simple operation interfaces
Common function keys are located on the operation panel for direct use, hot key function on screen for quick access.
8. ATC (automatic tool changer) and AGC(automatic guide chnger) can be installed
9. Unlimited number of machining conditions can be saved as machining archives. Each set of machining conditions can be edited, modified or stored. They are easy to edit and easy to search.
10. Automatic origin search and multi-point coordinate memory capability.
11. Chinese/English versions, Metric/British system switch and quick up, quick down, and slow up and slow down capabilities, resolution can reach 1um.
12. All alarms describe the source, data and exact time of problem occurrence.
13. Able to proceed standard GM code and extra GM code
14. Able to proceed DXF file transfer to position coordinate function
15. AB axis rotate table can be installed
16. Position simulation and work route can be displayed
17. During discharge change new electrode can automatically compensate depth
18. Backlash point automatic compensate function
19. Able to do single hole drilling, multiple hole drilling and multi thickness drilling
20. Blindhole drilling function, any depth can be set
21. Initial current can set to reduced value, which can prevent workjob surface damage
22. Initial polarity reverse function, can prevent uneven electrode caused efficiency decrease
23. Six axis linear interoperate accelerate speed movement
24. Input, output, various of machine status real time display system
25. Discharge program and parameter conversion function
Accessories
《 Standard Accessories for High-speed Drilling CNC EDM 》
Tool Box*1
Brass Electrode 1.0mm*10
Electrode Guide 1.0mm*1
Standard Chuck*1
Foot Pads*1 set
Filter*1
Rubber Seal*10
Halogen Work Lamp*1
Flushing Unit*1 set
《 Optional Accessories for High-speed Drilling CNC EDM 》
ATC
Electrode Guide(Other diameters)
Brass Electrode(Other diameters)
ER Type Chuck for electrodes up to 6mm
Submerged Work Tank
75Amp Power upgrade
Filtration System with Resin Bottle
A,B Axes
Automatic guide changer 3/6
REN AN INFORMATION TECHNOLOGY CO., LTD.
製品の説明 :
Just like the real CNC machine, equipped with exactly same overall appearance, actual handwheel and real machine operation panel as numerical control machine.
Solving the difficulties of real machine: precise, complicated and very expensive.
With CNC Simulator, everyone can learn CNC machine operation and accumulate hands-on operation skills.
CNC training machine is equipped with exactly same overall appearance, actual handwheel and real machine
operation panel as numerical control machine. Its purpose is to train students for accumulating CNC machine operation skills (program transmission, programming, tool selection, tool compensation and alarm clear )
Overall design is more attractive, and it emphasizes on interaction to make students less mistakes happened.
Not only decreasing learning cost but also letting students work and learn in the safe environment.
KAO MING MACHINERY INDUSTRIAL CO., LTD.
製品の説明 :
1. 三軸採用方形硬軌設計，滑動件為全行程支撐，無懸伸下垂之問題，結構剛強適合重切削。<br />
<br />
2. 門寬2.1米以下，底座採用雙軌設計；門寬2.3米以上，底座採用四軌之滑動與滾動複合化設計。<br />
<br />
3. Y軸橫樑為階梯之軌道設計，段差70mm確保加工精度與穩定性。<br />
<br />
4. 三軸使用高精度並施以預壓及預拉之滾珠導螺桿；X軸採中空設計並通過冷卻油，且螺桿兩端之稱軸承外環，有空氣冷卻之特殊設計，減少熱變形，確保最佳之定位精度。<br />
<br />
5. Y、Z軸滾珠導螺桿之安裝，其頭座與尾座係與橫樑及床鞍鑄成一體，確保最大剛性及精度。<br />
<br />
6. 機械式扭力限制器安全裝置，可避免機器在受到意外碰撞或操作錯誤時，重要機件不會因此被破壞。<br />
<br />
7. 刀庫為油壓分度馬達傳動；換刀臂之旋轉為油壓搖擺馬達驅動，確保ATC換到系統之快速、精確及穩定性。<br />
<br />
8. X軸8米以上四軌床身為線性導軌傳動，中央為主支撐兩側為滾子式履帶軸承輔助支撐，以增加傳動效率。<br />
GSTC TECHNOLOGY CO., LTD.
製品の説明 :
Our portfolio covers form knurling tools, cut knurling tools, knurling wheels and marking tools in market-leading technology and quality. Our innovative power is reflected in our modern tool systems and in the continuous optimization of our production processes. The intensive dialogue with tool users from all over the world helps us to permanently improve our product concept. Modular tool systems provide the decisive extra benefit with regard to flexibility, versatility and speed.
The longstanding experience in our core competence, the profiling of knurling wheels, enables us to offer a wide standard range of high-precision knurling tools, knurling wheels and marking tools and is at the same time the perfect basis for designing, developing and producing first-class individual tool systems which are exactly customized to any special requirement.
AUTOGRIP MACHINERY CO., LTD.
製品の説明 :
◎ Second Collet Changes Slash Setup Times.
◎ Industry-Leading Gripping Range.
◎ Ultra-Precision Accuracy.
◎ Parallel clamping over the entire clamping length
◎ Extreme Grip Force = Most Aggressive Chip Removal/Fastest Cycle Times.
◎ Maximum Rigidity Produces Superior Part Finishes.
◎ Best Tool Clearance - Critical For Live Tooling.
