GENTIGER MACHINERY INDUSTRIAL CO., LTD.
製品の説明 :
1. The double column saw frame structure raise rigidity.
2. The main driving wheels are equipped with an encoder for instant feedback and speed compensation.
3. Material sizing and cutting feed by servomotor.
4. The roller bed and dual movable jaw of F&R avoid material drag and squeezing.
5. The arch elevation mechanism uses a laser induction and isn’t limited by the material height and shape.
6. The sawing order can be scanned by QR CODE to establish the parameters and is beneficial for management.
7. Graphical dialogue operation screen, humanized operation, improving operation convenience.
8. Equipped with a multi-function meter that immediately monitors the instantaneous energy consumption and efficiency.
9. High-performance design and stable structure can get the best sawing flatness, reduce material waste and improve efficiency.
10. The machine combines fashion and technology while injecting the meaning of high speed, stability, and eco-friendly.
HO CHEN MACHINERY & ELECTRIC IND. CO., LTD.
製品の説明 :
XYZ axes travel: 500x400x185mm (20"x16"x7") inch
U axis travel: 300mm (12") inch
Z axis single travel: 400 mm (16") inch
Work table: 800x450 mm (31"x18") inch
Max. Workpiece: 1250x650x390 mm (49"x26"x15") inch
Max. Workpiece weight: 1400 kg
Max. Electrode weight: 185 kg
Machine net weight: 2100 kg
Oil level: 110-360 mm (4"-14") inch
Packing Size(LxWxH)：2340x2320x2500 mm (92"x91"x98") inch
Work Table to platen:
1. Z axis single travel: 230-630 mm (9"x25") inch
2. UZ axis: 230-715 mm (9"x28") inch
Filter： 1
Paper filter：2
Capacity：550 Liters
Machine Features
> Windows CE controller
> A dialog window with picture description.
> Special repaired frames to quicken the maintenance speed.
> Close-loop design of digital feedback on three axes of the machine significantly increases positioning precision and ORBIT-CUT machining accuracy and efficiency.
> Simple operation interface.
> Common function keys are located on the operational panel for direct use.
> Hot key setting.
> ATC (automatic tool change) and C-axis 360° index can be installed; the process of coarse machining to ultra-fine machining can be completed at one time.
> Dialogue diagram provides various hole-expanding modes such as quick search of edge, centers and datum marks.
> Rich color graphic (the same resolution as a PC screen).
> Automatic multi-step machining (coarse, medium coarse, medium fine, fine, superfine)—up to 10 steps.
> Unlimited number of machining conditions can be saved as machining archives. Each set of machining conditions can be edited, modified or stored. They are easy to edit and easy to find.
> Automatic origin search and multi-point coordinate memory capability.
> 1/2 design capability, ARC automatic discharge waveform detection and automatic adjustment.
> Automatic center position detection, automatic compensation, search of hole center and deepest point; fixed hole machining (cyclic mode, independent mode), which is suitable for different machining conditions; Radial, circular, square, linear (vector), coning, 45° hole-expanding machining.
> Three-axis beeline, two-axis arc, three-axis helix.
> Chinese/English versions interface, metric/British system switch and Z-axis quick up, quick down, slow up and slow down capability.
> Lateral machining, three axes, six directions (plane rotation).
> All alarms describe the source, date and exact time of problem occurrence.
> Optical scale is applied for close-loop position control, enabling extreme position for machining.
> Automatic editing—settings can be done according to type of material, work piece size, machining depth, one side die clearance, final current and rate of electrode wear.
> CNC models possess conventional capability of consistent level of energy discharge, achieving stable and rapid machining and smooth high quality on machining surface while the rate of electrode wear is still low.
> Monitor page indicates machining path and orbital pattern in use.
KTR TAIWAN LTD.
製品の説明 :
The recently developed DATAFLEX® 16 is available for measuring torque ranges of 10 Nm, 30 Nm and 50 Nm. The torque is measured using the well-approved technology of wire strain gauges combined with the latest electronic components.
The torque signals are processed without contact at a high resolution of 24 bit achieving an accuracy of 0.1 % of the terminal value. Supplementary to torque measuring the size 16 has a speed encoder providing two signals with a resolution of 360 pulses per revolution.
SAFEWAY MACHINERY INDUSTRY CORPORATION
製品の説明 :
Inserts / Jaw
Compatible with all safeway vises
Suitable for 3 types of material :
soft steel / hard steel / aluminium alloy
Each set includes 2 jaw plates
Gripper Set
Suitable for all safeway vises
One gripper contains :
holding teeth / dovetail / serration
OSCAR E.D.M. COMPANY LTD.
製品の説明 :
Quick Integration
EX/EXD Series electrical discharge
machine, capable of easy integrated with
MES system, online measurement,
storage system and etc via OPCUA, API.
Smart Production line
Actual application on automobile moulding industry in
Europe. EX series sinker EDM integrated with MES and
milling machine where perform the production just-intime
without any interruption. By increasing 30% of
overall equipment effectivenss (OEE), 2 EDM will then
bring out extra 3,000 hours working time per year
CHIEN CHENS MACHINERY CO., LTD.
製品の説明 :
Specification
Table size: 1515 x 470 mm
Longitudinal travel: 1300 mm
Cross travel: 600 mm
Y slide way width: 720 mm
Z Slide high: MAX 810 mm
Z Slide way width: 420 mm
Spindle taper: NT#40(BT)
Spindle motor: 5HP / 4P
Spindle speed: 70~3600 RPM
Feeding speed: 10~6000 mm/min
Ballscrew: Ø32 mm C5
Net weight: 3500 kgs
HEIDENHAIN CO., LTD. (TAIWAN)
製品の説明 :
Angle encoders for rotary and tilting axes are indispensable for machine tools on which high positioning accuracy and a high machining rate are essential. Because angle encoder measure angular motion of the axis directly and immediately. Mechanical transfer elements therefore have no influence on position measurement, both kinematics errors and the influences of forces are measured by the angle encoder and considered in the position control loop. This can eliminate a number of potential error sources: Gear errors, reversal error, errors due to deformation of the drive mechanics by machining forces.
FACTORY AUTOMATION TECHNOLOGY CO. ,LTD
製品の説明 :
CNC Vertical Lathe VL-25M
Description
✔Unique RAM Exchange Interface Design
The RAM has three special features. First, the unique interface design enables automatic tools exchange.
Second, the built-in power tools provide milling function.
Third, the precision indexed positioning facilitates wide milling and turning applications. Such characteristics can keep free of cutting force applying on bearing, thus prolonging the bearing lifespan.
✔Worktable with high loading capacity
The maximum allowable load of the worktable is 20 tons with a diameter of 2,700mm and it utilizes high-rigidity, high-precision crossed roller bearing with proper preload that is capable of resisting cutting load from all directions.
Specification
VL-25M
➣Capacity Other Item
Max turning diameter Ø3000 mm
Max turning height 1800 mm
Max torque 32200 N-m
➣Table
Size mm Ø 2700
Table load 20000 kg
Table rotation 1.6~160 rpm
Motor α40, 6000i
Motor(continuous/30 mins) 37/45 kW
➣Stork and Rapid
X axis stroke(Horizontal)(RAM) 2100 mm
Z axis stroke(Vertical)(RAM) 1200 mm
X axis feed rate(RAM) 0-8000 mm/min
Z axis feed rate(RAM) 0-20000 mm/min
Z axis stroke(Vertical)(Cross rail) 1500 mm
Rapid of cross rail 400 mm/min
➣Automatic Tool(Changer)
Tool number 1cover+5turning+6milling, ISO50
Shank size □32, Ø32/Ø40/Ø50 mm
➣Servo Motor
Table AC 37/45 kW
Cross rail AC 5.5 kW
Hydraulic power AC 3.7 kW
Table lubricating AC 0.37 kW
Slide lubricating AC 0.025 (2 set) kW
X axis α30i kW
Z axis α40iB kW
Power spindle 15/18.5 kW
➣Dimension
Floor space(WxDxH) 6250x4696x6410 mm
Machine weight 30000 kg
