Chen Ying Oil Machine Co., Ltd.
製品の説明 :
1. Fixed amount of oil feeding that can supply the required amount of oil to each lubricating point.
2. There are various choices of discharge volume, 0.1, 0.2, 0.3, 0.4 and 0.5cc per stroke. The discharge volume of each outlet can be different.
3. Each discharge outlet has a detective piston that can detect if the pipe system works functionally.
4. T type 0.5cc can be assembled either NO (Normal Contact) or NC (Normal Close) Contact sensor switch. It also can be set up as NO or NC Contact upon request. When it is set up as NO Contact, it sends signal during the operation time. When it is set up as NC Contact, it sends signal during the interval time.
5. T type volume distributors accumulate oil inside of the distributor and discharge oil during the interval time.
6. T type volume distributors have to work with oil pressure-relief type lubricators. The lowest operation pressure is 8 kgf/c㎡ and the max pressure is 30 kgf/c㎡.
7. The viscosity range of oil is 32 ~90 cSt @ 40℃.
HEIDENHAIN CO., LTD. (TAIWAN)
製品の説明 :
Collision protection is a major topic at HEIDENHAIN. The touch probes feature a large deflection path and offer additional safety with rated breaking points in the stylus or the connecting pin to the probe contact.
The TS 460 and TT 460 touch probes feature intelligent battery management in order to minimize current consumption. The touch probe switches in steps to the stand by condition: The longer a touch probe has been switched off, the less current it consumes. Activating a touch probe from a low standby level takes only a split second longer. This ensures high, application oriented availability.
A Sun Phototnics
製品の説明 :
"ATOM Micro-Diameter Drill" Challenges Semiconductor Ultra-Micro Hole Processing Technology
In response to the problem of micro-hole processing in chip packaging testing, ATOM has launched multiple solutions. The following two series are highly respected in the industry:
ADR Standard Series Drill
The minimum diameter of the ADR series can reach Ø 0.02mm, and the diameter tolerance is less than −0.005mm. It is suitable for micro-hole processing of materials such as steel, non-ferrous metals and resins. Yuewei Technology is the general agent of ATOM in Taiwan and China, with sufficient inventory and efficient delivery services.
ADR-SV Standard Coated Series Drill
The ADR-SV series drill has a wear-resistant FCS coating and is suitable for micro-hole processing of soft steel and high-hardness steel (HRC50). This series is designed with a wider chip groove and polished on the edge of the cutting edge, which significantly improves the chip removal smoothness and processing quality, and effectively extends the life of the drill.
Advantages and features of "ATOM micro-diameter drill" in semiconductor manufacturing
1. Extremely high precision
ATOM micro-diameter drill can achieve extremely high drilling accuracy on materials such as aluminum alloy and engineering plastic (PEEK). This is crucial for socket test sockets, because ICs are getting smaller and smaller in the process of rapid technological development. How to achieve the hole position accuracy required by customers in the manufacture of socket test sockets requires not only the stability of machine tools, but also the support of tools.
2. Excellent hole wall roughness and hole burr suppression
The hole wall roughness and hole burr suppression of micro-diameter drilling are directly related to the quality of the hole. Whether it is a blind hole (Blind Hole) or a through hole (Through Hole), ATOM micro-diameter drill can achieve smooth, burr-free, flawless hole wall roughness and hole, which helps product yield and remove burrs after processing.
3. Low loss and high production efficiency
When drilling, high-speed machining machines cause the temperature of the drill tip to rise due to the high speed, which leads to drill wear. ATOM micro-diameter drills use high-quality all-tungsten steel raw materials as the base material to achieve ultra-long tool life, thereby saving the problem of equipment stagnation due to tool change.
4. Full size and complete inventory
As the exclusive agent of ATOM micro-diameter drills, Yuewei Technology imports a full range of Japanese size series inventory, from Φ0.03~Φ1.00, with a standard inventory of Φ0.01, and a diameter ratio of 5D/10D/15D/20D, uncoated ADR or coated ADR-SV are all in stock in Taiwan, meeting the needs of today's increasingly shorter delivery time, and achieving the convenience of 2-day delivery.
5. Customizability
ATOM micro-diameter drills can be customized according to the needs of specific applications. Whether you need a stage forming drill, a high-diameter drill, or a water-out drill, you can customize it according to the drawing.
【Contact Information】
Tel: +886-2-26327601
Fax: +886-2-26327604
Line@ : https://line.me/R/ti/p/%40332yetoa
Website: https://asun-photonics.com/
HYDEX MACHINERY INDUSTRIAL CO., LTD.
製品の説明 :
The roller cam consists of an input cam shaft and a roller turret.
The roller cam is designed with rolling contact, featuring high rigidity, high speed, and outstanding durability.
Engagement between the roller and cam are preloaded to fully eliminate backlash that enables the roller and cam to exhibit their ultra-high precision feature.
Besides, with rolling contact to transmit kinetic energy, energy consumption during drive can be dramatically reduced. This enables the roller cam to achieve over 90% of transmission efficiency.
ATMAX TECHNOLOGY INTERNATIONAL CO., LTD.
製品の説明 :
YG started manufacturing mechanical type hobbing machines since 1963. "Hobbing is our everything" is the slogan in YG. From it, we can say that YG has very good experience in hobbing machines design, and manufacturing.
YG uses HERA as a name for their CNC hobbing machines series. They have wide network in Europe, America and Asia with experienced and professional companies sell HERA there. The HERA series hobbing machines are all full CNC control. They have strong and rigid machine frams. YG uses world class one transmission elements with Fanuc and Siemens full package controller and servo units on their HERA series . It makes HERA has good start point and it really does.
In Taiwan, ATMAX is the agent of YG. ATAMX helps YG sell the HERA series. It is successful already that there severl users are using HERA manufacturing their high precision gear parts.
We always welcome new friend joint us.
MATRIX PRECISION CO., LTD.
製品の説明 :
GHP-3540 applies the FANUC controller and high speed grinding spindle, through the in-house developed intelligent conversation window software, it can flexibly output the required tooth profile and grinding parameter.
The machining workpieces include the involute gears and cycloidal gears, the high efficiency and high precision expressed from the product are equivalent to worldwide top brand's ones. GHP-3540 is your best choice.
