CIN EY DIAMOND WHEEL COMPANY
製品の説明 :
We distribute the X-POWER superhard abrasive wheel dresser from San-Ei Seiko of Japan. This dresser efficiently and simultaneously dresses (eliminates runout and reshapes) and sharpens (refines) superhard abrasive wheels. Custom shapes and sizes are available to meet customer needs.
The X-POWER's features include:
1. Simultaneous dressing and sharpening of superhard abrasive wheels (CBN and diamond wheels).
2. Highly effective not only for resin-bonded superhard abrasive wheels but also for ceramic-bonded and metal-bonded superhard abrasive wheels.
3. Significantly reduced dressing time compared to traditional methods (such as soft steel grinding or dressing with conventional WA wheels).
4. Excellent cutting quality after dressing because the X-POWER removes the bond during grinding.
5. Simple construction and operation, requiring no special equipment.
6. Flexibility: Customizable shapes to suit various applications and compatible with all equipment.
7. Single-process dressing: A single dressing operation using a dressing tool of the same shape as the finished product significantly increases equipment uptime.
8. Elimination: Eliminates dust generated by traditional grinding wheels such as WA and GC, contributing to environmental protection and improving operational safety.
11 standard sizes of X-POWER dressers are available; please refer to the attached images. Custom sizes and shapes can also be manufactured to meet specific needs.
The attached catalog provides a comparison of the dressing and sharpening effects of CBN170N100 (resin-bonded) grinding wheels using the soft steel grinding method (S50C) and X-POWER (model SX-A1) methods.
We also provide experimental data showing that the dressing effect of X-POWER on CBN400 grinding wheels with different bonds is dozens of times greater than that of S50C. A comparison of the dressing ratio of CBN grinding wheels and diamond grinding wheels using X-POWER is also available.
Finally, we presented another experiment: using an X-POWER (model SX-D1) dresser with a BN170P100BS60-10 grinding wheel, and moving a dressing block left and right against the wheel, we varied only the wheel's peripheral speed in the dressing conditions, resulting in different amounts of wheel reduction, dressing block reduction, and dressing ratio. Based on the experimental records, a wheel peripheral speed of approximately 450-750 m/min is recommended for dressing.
Through the information in this catalog, we hope to provide you with a deeper understanding of the San-Ei Seiko X-POWER dresser we distribute. Industry professionals are welcome to contact us for more detailed product information and pricing.
GUANG DAR MAGNET INDUSTRIAL LTD.
製品の説明 :
● Very easy operation with the special design of ON/OFF switch. Easy-Locked function, provides you switch on and lock the handle at the same time.
● Working-piece surface will not be damaged during the working.
● High holding magnetic power, this lifter cans be used successive. Electro power is no necessary for the lifter to avoid power failure problem.
PATENT NO: M313672
A Sun Phototnics
製品の説明 :
Product Advantages / Key Features
■ High Precision
■ High Safety
■ High Rigidity & High Clamping Force
■ Coolant-Through Design
■ High Balance
High Precision
Industry-first Total Runout Accuracy Guaranteed within 5 μm
Only YUKIWA can offer this level of guarantee.
Conventionally, the accuracy of a collet chuck refers only to the precision of the collet itself. Most manufacturers do not take into account the total runout accuracy, including the holder body.
YUKIWA’s Super G1 Chuck thoroughly optimizes the holder body, clamping nut, and collet as a complete system. By minimizing deviations among the holder body, nut, and collet, YUKIWA achieves the industry’s first guaranteed total runout accuracy within 5 μm—the precision level users truly demand.
High Rigidity & High Clamping Force
Outstanding Performance in Heavy-Duty Milling Operations
■ In high-speed and high-efficiency machining, excellent runout accuracy alone is not sufficient. Clamping force and rigidity are equally essential.
■ High rigidity is ensured by reducing the collet overhang from the holder body and increasing the wall thickness of the collet insertion area.
■ The collet taper adopts a 1/10 taper (5°23′29″), increasing clamping force by 1.5 times compared to conventional YUKIWA products.
This enables the Super G1 Chuck to fully demonstrate its performance in high-speed and heavy milling applications, including the use of high-performance end mills.
High Balance
Stable Even Under High-Speed Cutting
■ Balance is another critical factor in high-speed machining.
■ By precision grinding the V-flange front face and neck area of BT tool holders, the Super G1 Chuck achieves excellent dynamic balance, ensuring stable operation at high spindle speeds.
Superior Surface Finish
The surface roughness of machined workpieces can vary significantly.
If tool holder rigidity is insufficient, chatter occurs during machining, resulting in inconsistent surface quality. While conventional milling chucks may offer strong clamping force, they do not necessarily provide high rigidity.
The Super G1 Chuck delivers exceptional rigidity, suppressing chatter during milling operations. No secondary finishing is required—you can clearly see the difference in the final machined surface.
Reduced Tooling Costs
Shrink-fit holders provide stable performance, but their runout accuracy cannot match that of the Super G1 Chuck.
The example on the right shows a customer application using the Super G1 Chuck, where minimized runout significantly reduces tool wear and increases the number of holes drilled per tool.
Better runout accuracy = Lower tooling costs.
Over time, this contributes substantially to overall cost reduction.
Shorter Tool Change Time
With the Super G1 Chuck, tool changes are quick and easy—simply open and close the collet using a dedicated wrench. No shrink-fit heating device is required.
This greatly reduces non-productive “changeover time.”
Additionally, time spent adjusting runout accuracy increases machining hours and costs. Many customers report:
“Achieving high-precision tool mounting in a short time leads directly to cost savings.”
【Contact Information】
Tel: +886-2-26327601
Fax: +886-2-26327604
Line@ : https://line.me/R/ti/p/%40332yetoa
Website: https://asun-photonics.com/
MATRIX PRECISION CO., LTD.
製品の説明 :
Matrix (Formed as Luren) was established in 1994. In these years, it developed the designing software, machine tools, gear cutters, such as, hobs, carbide hobs and shaving cutters, master gears and maintenance for the cutters.
Matrix (Formed as Luren) has integrated a producing system to provide the high quality products because offer a 100% perfection products is our goal. We are not only strict control the production line, but also every product is inspected tightly. We keep to improve the producing system to face more challenges and various requests from the customers. For instance, Matrix (Formed as Luren) has developed many kinds of grinding and resharpening machines to enhance the producing efficiency.
We always offer the best quality of gear cutters; widespread range of products, and fastest delivery date to satisfied the customer's needs.
HUNG CHIH LIMITED COMPANY
製品の説明 :
GROB’s products range from general machining centers to highly flexible automated production systems, from machining assembly units to fully automated assembly lines. Furthermore, motor production and assembly equipments for battery and fuel cell technology are also included in the product range. GROB has thermal spray technology suitable for engine components and can provide customized solutions for the processing of turbine casings, frame structure workpieces, chassis workpieces and battery casings.
Under the framework of Industry 4.0, GROB has taken an important step and launched the GROB-NET4Industry software for future-oriented digital and networked production. GROB has also successfully entered the field of additive manufacturing and developed a new liquid metal printing equipment.
JIN LI CHENG CUTTING TOOL CO., LTD.
製品の説明 :
※Special chip out and geometric flute design. Excellent chip out perfomance without burrs. For various materials including the ductile stainless steel.
※Multinational patented drill point angle and double ute design. Great wear out resistance Keep long time precise drilling.
※With both function of Drill and Reamer design and its accuracy tolerance is within 0.01mm. It also can save tool change time while processing.
※With European carbide round bar and exclusive cutting angle design, We run the polish process on all the end mills, and it leads the tools easy to remove chips and keep the double life time than other competitors.
※Based on Europe composite coating with internal coolant holes, it leads the JLC at drill much longer life time and reduce customer lots of processing cost.
HABOR PRECISION INC.
製品の説明 :
Smart, energy-saving and high-accuracy DC inverter cooling machine can save more than 60% of electricity consumption through speed control and frequency conversion technology, and optimize the refrigerant system to reduce the amount of refrigerant used, which can also reduce the GWP value.
FACTORY AUTOMATION TECHNOLOGY CO. ,LTD
製品の説明 :
CNC Horizontal Boring & Milling Machine
BMC-135TN Features
135 mm Spindle Diameter
Moving column construction
T Type Construction Base
➣Optional X/Y/Z axis travel, flexible for various machining requirements.
➣BMC-135TN can perform extreme precision machining, powerful milling and drilling processes among similar machines in the market.
This machines can be individually tailored to meet the costumer's requirements by choosing from comprehensive options and equipment.
➣Travel
Table cross travel (X): 3000/4000(option) mm
Head stock travel (Y): 2500/3000(option) mm
Table longitudinal travel (Z) : 1500/2000(option) mm
➣Table
Table size: 2200 x 2200 ｍｍ
Table load: 15000 kg
➣Spindle
Spindle Stroke (W): 800mm
Spindle Diameter: 135mm
Spindle Motor(continuous/30 mins) :30 / 37 kW
Spindle Speed range low : 30 / 37 kW
Spindle Speed range high : 579- 3000rpm
➣Machine dimension
Height: 5080/5525 mm
Floor space(W×Ｌ×Ｈ)：7200 x 7500 / 8200 x 8000 mm
Machine Weight: 33000/34000 kg
GP MACHINERY CO., LTD.
製品の説明 :
The Hiteco birotary heads series Tilt HX PLUS (90 °) are ideal for light alloys, composite materials and plastics working. Discover the liquid cooled electrospindles available with the various configurations.
Advantages:
1. Designed for machining composite materials, plastic and light alloys
2. Optimisation of the machining times thanks to the high positioning speeds
3. Excellent stiffness despite the light weight
